Metra Electronics 95-7321 - Kit Assembly and Installation; Double DIN; Stacked ISO DIN Head Unit Mounting; Final Dash Reassembly

4
Locate the factory wiring harness in
the dash. Metra recommends using
the proper mating adapter from
Metra or AXXESS. Re-connect the
negative battery terminal and test
the unit for proper operation.
1
A
Attach the Double DIN brackets to
the inside edge of the Double DIN
trim plate. (Figure A)
2
Slide the Double DIN head unit or
stacked ISO head units into the
bracket/radio housing assembly and
secure the Double DIN head unit or
stacked ISO head units to the
assembly using the screws supplied
with the radio. (Figure B)
3
Reassemble dash in reverse order of
disassembly.
4
DOUBLE DIN / STACKED ISO DIN
HEAD UNIT PROVISION
B
95-7321
KIT ASSEMBLY
