1. Unclip and remove panel surrounding
shifter. (Figure A)
2. Remove (2) Phillips screws at bottom
corners of panel surrounding radio.
(Figure B)
3. Unclip and remove entire panel
surrounding radio including the clock
and a/c vents. (Figure C)
4. Remove (4) Phillips screws
securing radio.
5. Unplug and remove the radio.
Continue to kit assembly
3
Dash Disassembly
95-7323
(Figure A)
(Figure B)
(Figure C)
