1. Unclip and remove the shifter trim
panel. (Figure A)
2. Unclip and remove the radio/climate
control trim panel. (Figure B)
3. Unclip and remove the display trim
panel above radio. (Figure C)
4. Remove (4) Phillips screws securing
the radio.
5. Remove (4) Phillips screws securing the
climate control to the factory trim panel.
Continue to kit preparation
3
Dash Disassembly
95-7339
(Figure A)
(Figure B)
(Figure C)
