95-8154 KIT ASSEMBLY
2
Snap the Double DIN Brackets onto
the Double DIN Radio Housing.
(Figure A)
1
Slide the factory climate controls into
the Bracket/Radio Housing assembly
aligning the top of the assembly with
alignment pins in the bottom of the
climate controls and secure using the
factory hardware.
(Figure B)
2
Slide the Double DIN or stacked ISO
mount units into the bracket/radio
housing assembly and secure the
Double DIN or stacked ISO mount
units to the assembly using the
screws supplied with the Double DIN
or stacked ISO mount units.
(Figure C)
3
Continue to final assembly.
A
B
C
LEXUS GS SERIES 1993-1997
DOUBLE DIN RADIO
STACKED ISO MOUNT UNITS PROVISON
Note: Refer also to the instructions included with the aftermarket radio.
