3
95-8204 KIT ASSEMBLY
B
A
STACKED ISO UNITS PROVISION
Slide the stacked ISO units into the
Double DIN brackets and secure the
units to the brackets using the screws
supplied with the units.
(Figure B)
2
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
Snap the Double DIN trim plate into the
factory trim panel.
(Figure A)
1
