Metra Electronics 95-8208 - Stacked ISO Units Provision; Attach Brackets for Stacked ISO; Install Stacked ISO Units; Install Trim Plate for Stacked ISO

95-8208 KIT ASSEMBLY
3
B
A
C
STACKED ISO UNITS PROVISION
Slide the stacked ISO units into the
bracket/housing assembly and secure
the units to the assembly using the
screws supplied with the units.
(Figure B)
2
Snap the Double DIN Trim plate into
the Radio Housing.
(Figure C)
3
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
Snap the Double DIN brackets to the
inside edge of the radio housing.
(Figure A)
1
