Metra Electronics 95-8902 - Page 2

Subaru Forester (with DVD based NAV) 2009-2013/Forester 2009-2013/
Impreza WRX 2013-up/Impreza WRX STI 2008-2012/
Subaru Impreza 2008-2011
1
2
3
4
5
PTY/CAT
MENU
CD/AUX
FM/AM
SAT
TEXT
RPT
SCAN
TUNE/TRACK/CH
VOLUME
(Figure B)
2
1. Unclip and remove the trim panel surrounding the
factory radio including the A/C vents. (Figure A)
2. Remove (4) Phillips screws securing the radio.
Unplug and remove the radio.
Continue to kit preparation
Dash Disassembly 95-8902
(Figure A)
