Metra Electronics 95-8902 - Page 3

3
Kit Assembly 95-8902
Double DIN radio provision
(Figure B)
1. Snap the double DIN brackets to the inside edge
of the radio housing. (Figure A)
2. Slide the double DIN radio into the bracket/radio
housing assembly and secure the radio to the
assembly using the screws supplied with the
radio. (Figure B)
3. Locate the factory wiring harness in the dash.
Metra recommends using the proper mating
adapter from Metra or AXXESS. Re-connect the
negative battery terminal and test the radio for
proper operation.
4. Reassemble dash in reverse
order of disassembly.
(Figure A)
