Metra Electronics 99-1003 - Kit Assembly; DIN Mount Radio Assembly

99-1003 KIT ASSEMBLY
DIN MOUNT RADIO
* Note: Refer also to the instructions included with the aftermarket radio.
8
B
A
C
Slide the radio into the DIN
cage/housing assembly until it
snaps into place. (Figure C)
2
Continue to final assembly.
Slide the DIN cage into the radio
housing and secure by bending the
metal locking tabs outward.
(Figure B)
1
NOTE: For Sportage 1995-97 and
1998-03 secure the Mounting
Brackets to the Radio Housing with
(4) Captive Studs and (4) Pal Nuts.
(Figure A)
