4
99-1003 DASH DISASSEMBLY
SPORTAGE 1995-1997
Remove ashtray and (2) Phillips
head screws inside ashtray cavity.
2
Unclip and remove dash trim panel.
3
Remove (4) Phillips head screws
securing the radio. Unplug and
remove the radio.
4
Continue to kit preparation.
*
Note: Refer also to the instructions included with the aftermarket radio.
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
To Next Page
