99-1003 KIT PREPARATION
KIT ASSEMBLY PREPARATION
RIO 2001
SEPHIA 1995-1997
SEPHIA 1998-2001
SPECTRA 2000-2001
Continue to kit assembly.
* Note: Refer also to the instructions included with the aftermarket radio.
Cut and remove mounting tabs “B”
from Radio Housing #2. (The tabs can
be identified by the letter stamped on
the back of each tab.)
(Figure A)
Cut and remove mounting tabs “A” from
Radio Housing #2 and the mounting
brackets. (The tabs can be identified by
the letter stamped on the back of each
tab.) Locate the scored line on the back
of the radio housing and break away
the bottom portion of the housing as
shown.
(Figure C)
SPORT
AGE 1998-2003
Cut and remove mounting tabs “A” from
Radio Housing #1. Cut and remove tabs
“B” from the mounting brackets. (The
tabs can be identified by the letter
stamped on the back of each tab.)
(Figure D)
Cut and remove mounting tabs “B”
from Radio Housing #1. (The tabs can
be identified by the letter stamped on
the back of each tab.) (Figure B)
"B"
"B"
B
"A"
"A"
"B"
"B"
"B"
"B"
D
"B"
"B"
A
"A"
"A"
"A"
"A"
"A"
"A"
C
SPORTAGE 1995-1997
