2
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
Insert a small flat blade screwdriver in
between the radio and the switch panel
at top of radio and pry up and out to
remove switch panel
. (Figure B)
1
3
Remove (3) 9/32 screws
• (1) from the top (Figure C) and
• (2) from the bottom to remove radio.
(Figure D)
4
Remove the (6) retaining nuts securing
the radio and climate control to the fac-
tory bracket assembly and slide the cli-
mate control outward.
(Figure E)
5
Remove (2) 9/32 screws on each side of
the ashtray assembly and (1) in the mid-
dle underneath ashtray insert.
(Figure A)
2
99-2005
DASH DISASSEMBLY
Continue to kit assembly
CADILLAC SEVILLE 1998-2005
CADILLAC DEVILLE CONCOURS
(CONSOLE SHIFT) 1996-1999
A
B
C
D
Rem
ove
3
Ret
ain
ing
Nu
ts
Per
Si
de
E
