5
99-2005
KIT ASSEMBLY
S-E
S
-E
D
D
D
D
98-
04
S
98-
04 S
98-
04
S
A
B
C
D
Slide the climate control assembly into
the bracket / housing assembly and
attach with the factory hardware.
(Figure C)
3
When DIN mounting slide the included
spacer onto the DIN cage that came with
your aftermarket radio before inserting it
into the housing.
(Figure D)
4
Remove all tabs except the ones marked
98-04 S from the radio housing.
(Figure A)
1
Slide the 98-04 S radio housing bracket
onto the 99-2005 until side clips engage.
(Figure B)
2
Continue to kit assembly
CADILLAC SEVILLE 1998-2005
CADILLAC DEVILLE CONCOURS
(CONSOLE SHIFT) 1996-1999
NOTE: In order to DIN mount in the 2000-2004 Deville you will need to use the provided
spacer as described below. There is not enough depth to ISO mount or DIN mount without
the spacer.
