4
99-2005
KIT ASSEMBLY
Remove all tabs except the ones marked
S-E from the radio housing. (Figure A)
Slide the climate control assembly into
the bracket / housing assembly and
attach with the factory hardware.
(Figure C)
1
3
Slide the S-E radio housing bracket onto
the 99-2005 until side clips engage.
(Figure B)
2
CADILLAC ELDORADO 1996-2002
CADILLAC SEVILLE 1996-1997
S-E
S-E
D
D
D
D
98-
04
S
98-
04 S
98-
04
S
A
B
C
Continue to kit assembly
