Metra Electronics 99-2008 - Double DIN Radio Provision Assembly

99-2008 KIT ASSEMBLY
5
DOUBLE DIN RADIO PROVISION
Cut and remove the center bar from
the radio housing.
(Figure A)
1
Snap the Double DIN brackets to the
inside edge of the radio housing.
(Figure B)
2
Slide the Double DIN radio or stacked
ISO mount units into the bracket/radio
housing assembly then secure to the
assembly using the screws supplied
with the radio or ISO mount units.
(Figure C)
3
4
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
A
B
C
Snap the Double DIN Trim plate onto
the front of the Radio Housing.
(Figure C)
