Metra Electronics 99-3042 - Chevrolet S-10 Pickup;Blazer Dash Disassembly; Saturn Dash Disassembly; Kit Assembly Instructions; General Kit Assembly

3
Dash Disassembly
"B"
“B”
1. Unclipthedashtrimbezel.(FigureA)
2. Remove(4)hexheadscrewssecuringthefactory
headunitanddisconnectthewiring.
3. Cutandremoveallmountingtabsontheradio
housingEXCEPTtabs“A”.(FigureB)
Continue to kit assembly
Chevrolet S-10 Pickup 1986-
1993, Chevrolet S-10 Blazer/
GMC S-15 Pickup/Jimmy
1986-1994, Oldsmobile
Bravada 1991-1994
(Figure A)
4. Remove(4)Phillipsheadscrewssecuringthe
radio.Disconnectandremovetheradio.
Continue to kit assembly
Saturn (all models) 1991-1994
(Figure A)
(Figure B)
"A"
“A”
(Figure B)
Kit Assembly
(Figure A)
(Figure B)
MetraorAXXESS.Re-connectthenegativebattery
terminalandtesttheunitforproperoperation.
5.Screwtherearsupportbulletontotheboltonthe
backoftheaftermarketheadunit(“A”).
6.Mounttheradio/kitassemblytothesub-dashwith
thosescrewspreviouslyremoved.(FigureB)
7.Reassembledashinreverseorderofdisassembly.
1. Unclippowerwindowcontrolpanel.Disconnect
andremovepanel.
2. Pulloffclimatecontrolknobs.
3. Unclipandremovethedashtrimpanel.(FigureA)
Saturn (all models) 1991-1994
Kit Assembly
DIN head unit provision
1.Cutandremovetheshaftsupportsfromthe
radiohousing.
2.SlidetheDINcageintothekitandsecureby
bendingthemetallockingtabsdown.(FigureA)
3.Slidetheaftermarketheadunitintothecageuntil
secure.(FigureA)
4.Locatethefactorywiringharnessinthedash.Metra
recommendsusingthepropermatingadapterfrom
