99-5026
1
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Unclip and remove shift lever trim
panel.
(Figure A)
2
FORD MUSTANG 2001-2004
Unclip and remove the entire panel
surrounding the radio and climate
controls including the vents.
(Figure B)
3
Remove (2) 9/32” screws securing
radio.
(Figure B)
4
DASH DISASSEMBLY
A
B
To Next Page
