Metra Electronics 99-5026 - Lincoln Navigator 2003-2006 Dash Disassembly

4
99-5026
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Open center console and remove (1)
push pin from back of power window
switch panel.
(Figure A)
2
LINCOLN NAVIGATOR 2003-2006
Unclip and remove panel.
3
Remove (2) 9/32” screws exposed
on shifter panel then unclip and
move shifter panel off to side.
(Figure B,C)
4
Remove (2) 9/32” screws exposed
under ashtray assembly. (Figure C)
5
Unclip and remove entire panel sur-
rounding climate controls and radio.
6
Remove (2) 9/32” screws securing
radio. (Figure C)
7
DASH DISASSEMBLY
INSIDE CENTER CONSOLE
TOP VIEW
TOP OF SHIFTER TRIM PANEL
5
4
7
7
A
B
C
