99-5026
KIT ASSEMBLY
6
2
A
Slide the aftermarket head unit into
the cage and secure. Snap the trim-
plate into the radio housing.
(
Figure B)
3
Thread the rear support bracket onto
the back of the head unit (or cage)
and secure with the mounting nut
supplied. (
Figure C)
Slide the DIN cage into the housing
and secure by bending the metal
locking tabs down. (
Figure A)
1
NOTE:
On Ford Expedition and Lincoln
Navigator DIN head and ISO kit
assemblies, you must cut the Rear
Support Bracket for clearance.
(
Figure D)
4
B
C
REAR VIEW HEAD UNIT
REAR SUPPORT BRACKET
D
DIN HEAD UNIT PROVISION WITH POCKET
