Unclip and remove the gauge cluster
trim panel. (Fig. D)
Unclip and remove the trim panel/
speaker grill from above the radio
trim panel. (Fig. D)
Remove (4) Phillips screws from the
cup holder trim panel then unclip
and remove the panel.
(Fig. E)
Remove (4) Phillips screws from
the shifter trim panel then slide it
backwards. Note: There is no need
to remove this panel completely.
(Fig. F)
D
E
F
2010 FORD TAURUS
99-5721 DASH DISASSEMBLY
