Disconnect the negative battery terminal
to prevent an accidental short circuit.
Unclip and remove the small rectan-
gular trim around shift lever.
(Figure A)
1
2
Unclip and remove the entire panel
(including cup holders) surrounding the
shift lever.
(Figure B)
3
A
FORD FIVE-HUNDRED 2005-2007, FORD TAURUS 2008-09
MERCURY MONTEGO 2005-2007, MERCURY SABLE 2008-09
B
Remove (2) 9/32” screws at the bottom
of the center radio/ climate control
panel.
(Figure C)
4
Unclip and remove the center panel.
(Figure D)
5
Remove (4) 9/32” screws from the radio
to remove.
(Figure E)
6
C
D
E
3
99-5812
DASH DISASSEMBLY
Continue to kit assembly
