99-7425 DASH DISASSEMBLY
NISSAN Rogue 2008-10
A
B
C
1
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
If equipped with center speaker:
Unclip and remove the grille
(Figure A).
Remove (4) Phillips screws
securing the speaker. Unplug and
remove the speaker.
(Figure B).
Unclip the panel above the radio
including the a/c vents, then unplug
hazard switch and remove.
(Figure C)
2
Continued on page 2.
Note:
If not equipped with center
speaker skip step number 2.
