MAZDA BT-50 2006-UP
99-7517S DASH DISASSEMBLY
Remove three climate control knobs
and two Phillips screws from behind.
(Fig. A)
Using a panel removal tool, unsnap
and remove radio/climate panel.
(Fig. B)
Remove the fresh air and
recirculation air stickers from the
factory panel and place them in the
appropriate locations on the Metra
kit.
Remove the hazard button and AC/
defrost buttons from the factory
panel, and install them onto the
Metra kit.
1
2
3
4
A
B
