Metra Electronics 99-7603 - Dash Disassembly; Remove Upper Dash Panel; Kit Assembly

99-7603
2
Dash Disassembly
– Nissan Versa 2007-2011 ................................................................................2-3
Kit Assembly
– DIN radio provision with pocket ......................................................................... 3
– ISO radio provision with pocket
.......................................................................... 4
– Double DIN radio provision
................................................................................. 5
Table of Contents
1. Unclip and remove the panel above
the radio. (Figure A, B)
2.
Remove (2) Phillips screws
securing the radio trim panel then
unclip and remove the entire panel
surrounding the radio and A/C
controls. (Figure C)
Continued on next page
Nissan Versa 2007-2011
(Figure C)(Figure A)
(Figure B)
