Metra Electronics 99-8205 - Dash Disassembly

99-8205
1
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Unclip the bottom edge of the radio
trim panel then lift up and out to
remove.
(Figure A)
2
TOYOTA MATRIX 2003-2008
PONTIAC VIBE 2003-2008
Remove (4) 10 MM bolts securing
the factory radio.
(Figure B)
3
DASH DISASSEMBLY
A
SCAN
SEEK
TRA
CK
TUN
E
AM
FM1
FM2
DISK
B
