99-8213
1
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Unsnap panel with vent on driver’s
side and remove.
(Figure A)
2
TOYOTA PRIUS 2004-2005
Remove (2) Phillips screws on panel
below steering column with hood
release on it and remove panel.
(Figure A)
3
Unclip and remove panel surrounding
under side of steering column..
(Figure B)
4
Unclip and remove panel above
steering column.
(Figure C)
5
DASH DISASSEMBLY
A
B
C
Unclip and remove vent panel sur-
rounding the shifter.
(Figure D)
6
D
Open glove box and remove vent
panel next to the radio.
(Figure D)
7
To Next Page
