TOYOTA 4 RUNNER 2010
99-8227S DASH DISASSEMBLY
4
6
5
7
Unclip and remove the vents from
the factory radio panel. (Fig. D)
Remove the (2) Phillips screws
securing the trim panel on the top of
the factory radio panel. (Fig. E)
Remove the (4) Phillips screws
securing the outer a/c vent control
wheel trim pieces. (Fig. F)
Unclip and remove the hazard
switch from the factory radio trim
panel. (Fig. G)
D
E
F
G
