Metra Electronics 99-8715 - DIN Radio Provision With Pocket

99-8715 KIT ASSEMBLY
2
Slide the DIN cage into the radio
housing and secure by bending the
metal locking tabs outward. (Figure A)
1
Slide the aftermarket radio into the
cage until it snaps into place.
(Figure B)
2
Snap the pocket into the radio hous-
ing. (Figure C)
3
Continue to final assembly.
A
B
C
Note: Refer also to the instructions included with the aftermarket radio.
DIN RADIO PROVISION WITH POCKET
