1. Unclip the shifter trim panel, then unclip
the shifter boot from the panel. Slide
the shifter boot through the panel, then
unplug and remove the panel. (Figure A)
2. Unclip the ashtray and set to the side.
(Figure B)
3. Remove (2) T-20 Torx screws securing the
bottom of the climate control panel, then
unplug and remove the panel. (Figure C)
(Figure D)
(Figure E)
DASH DISASSEMBLY
(Figure A)
(Figure B)
(Figure C)
4. Open the cup-holder, then unclip,
unplug, and remove the hazard button
panel. (Figure D)
5.
Remove (4) T-20 Torx screws securing the
radio, then unplug and remove the radio.
(Figure E)
Continue to Kit Assembly
