Metra Electronics 99-9011 - ISO HEAD UNIT PROVISION WITH POCKET ASSEMBLY

7
99-9011
KIT ASSEMBLY
Snap the pocket into the radio hous-
ing.
(Figure C)
4
Slide the head unit into the radio
opening until the side clips
engage. (Figure B)
2
Snap the ISO Trim Plate into the
Radio Housing.
(Figure C)
3
ISO HEAD UNIT PROVISION WITH POCKET
A
B
C
Mount the ISO Brackets to the
head unit with the screws sup-
plied with the unit.
(Figure A)
1
