99-9501 DASH DISASSEMBLY
JAGUAR S-TYPE 2003-2008
NON-NAV MODELS
D
2
Continue to kit assembly
Remove (4) screws securing the
r
adio/climate control assembly to the
dash. Unplug and remove assembly.
(
Figure D)
Remove (4) screws securing the radio
to the assembly and remove the
radio. Retain the assembly for re-use
during kit assembly.
6
5
C
Unclip and remove the trim panel sur-
rounding the radio/climate
controls/ashtray and front half of the
center console.
(Figure C)
4
To Next Page
