99-9501 DASH DISASSEMBLY
JAGUAR S-TYPE 2003-2008
NON-NAV MODELS
A
B
1
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Remove cup holder and (2) screws
securing center console storage com-
partment and remove compartment.
(
Figure A)
2
Unclip and remove the trim panel
around the shifter.
(Figure B)
3
Continued on page 2
