99-9501 DASH DISASSEMBLY
JAGUAR X-TYPE 2002-2008
NON-NAV MODELS
A
B
C
3
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Unclip and remove the trim panel
around the shifter. ( Figure A)
2
Remove (2) screws from bottom edge
of ashtray assembly then unclip and
remove ashtray assembly. (Figure B)
3
Remove (2) screws from inside ash-
tray cavity at bottom edge of radio.
(Figure C)
4
Continued on page 4
