BT-HD01
4
Fairing Disassembly
Roadglide/Sharknose models
1. Loosen (6) T-25 Torx bolts from
bottom, middle and top of left and
right sides of the inner fairing.
(Figure A)
2. Use a 1/2” socket or box wrench
to remove the (2) acorn nuts that
hold each turn signal at the lower
fairing. Let the signals hang loose.
(Figure B)
3. Lift away the fairing, unplug the
headlights and remove.
(Figure A)
(Figure B)
Step 1 Step 1
