Metra Electronics BT-HD01 - Fairing Disassembly; FLH;Batwing Models

BT-HD01
3
Fairing Disassembly
FLH/Batwing models:
1. Cover the front fender.
2. Remove (2) T-27 Torx bolts from
inner fairing (under mirrors)
(Figure A, step 2)
3. Remove (2) T-27 Torx bolts from
outer edges of inner fairing near the
fork tubes (facing forward)
(Figure A, step 3)
4. Remove (3) T-27 Torx bolts from
bottom edge of windshield.
(Figure A, step 4)
Note: Windshield and fairing will
be loose once these screws are
removed. Use extreme caution not
to damage fairing or windshield.
5. Remove windshield taking caution
that the outer fairing is loose.
6. Lift away and unplug headlight to
remove outer fairing. (Figure B)
(Figure A)
(Figure B)
Step 2 Step 2
Step 3
Step 4
