DASH DISASSEMBLY
1. Unclip and remove the panel below the
steering column. Remove (2) Phillips
screw exposed. (Figures A,B)
2. Unclip, unplug, and remove the climate
control panel. (Figure C)
(Figure D)
(Figure E)
3. Remove (2) Phillips screws securing
the radio trim panel, then unclip and
remove. (Figure D)
4. Remove (1) Phillips screw securing the
dash pad, then unclip and remove.
(Figure E)
(Figure A)
(Figure B)
(Figure C)
