DASH DISASSEMBLY
9. Remove (4) 10mm screws and (1) 8mm
screw securing the dashboard brace.
The brace only needs loosened to aid in
removing the speaker pod in the next
step. (Figure K, L)
(Figure L) (Figure N)
(Figure M)(Figure K)
10. Remove (3) Phillips screws securing
the speaker pod, then unclip, unplug,
and remove. Gentle aggression will be
required to remove the pod. (Figure M)
Note: There is an electronic module
attached to the back of the pod which
must be removed and reused in
Kit Assembly. (Figure N)
To Next Page
