MI 3200 TeraOhm 10 kV Instrument Description
5
2. Instrument Description
2.1. Instrument Casing
The instrument is housed in a plastic box that maintains the protection class defined in
the general specifications.
2.2. Operator’s Panel
The operator’s panel is shown in the figure below (Fig.1).
Fig. 1. Front panel
Use original test accessories only!
Max. allowed external voltage between test terminals and ground is 600V!
Max. allowed external voltage between test terminals is 600V!
Disconnect all test leads, mains supply cable and switch off instrument
before removing the battery cover – Hazardous voltage!
