Metrix HI 803 - DI-103 Installation for A & B Axes

Doc# 0296-0018 • REV R (July 2017) Page 20 of 61
REF.
INPUT
MODE CURSOR
HELP
SELECT
100 10K1K
FREQUENCY RANGE
Hz
FREQUENCY
RUN
STORE
AMPLITUDE
ABC
7
PQR
6
MNO
5
JKL
4
GHI
9
DEF
8
STU
1
VWX
2
YZ -
3
0
SPACE
PRINT
PAPER
ADV
HI 803
TRANSDUCER TEST SET
50 mV/g
RS-232
Input Connector
FIG. 3-12 TOP PANEL/INPUT CONNECTOR
A
DC
B
FIG. 3-13 ACCELEROMETER CONNECTOR PIN OUT DIAGRAM
Pin Funcon
A SIG A AXIS
B SIG B AXIS
C SIG C AXIS
D GROUND
TABLE 3-1: ACCELEROMETER CONNECTOR PIN AND FUNCTION
DI-103 Installaon for A & B Axes
Step 5. Posion the TUT for the A posion. (See Fig. 3-14)
NOTE: For Triaxial Mounted Specicaons go to Chapter 2, Triaxial Mounted Specicaons.
