Data Format
The data is transferred as a comma delimited ASCII le. There is one line in the le for each reading
made. All readings are in standard English units (G’s Peak, IPS Peak, or MILS P-P). Each line has the fol-
lowing elds which appear in the order shown:
1. DATE OF READING
2. TTS SERIAL NUMBER
3. TEST NUMBER
4. TEST PAGE LETTER
5. TRANSDUCER MODEL NUMBER STRING
6. TRANSDUCER SERIAL NUMBER STRING
7. TRANSDUCER MASS IN GRAMS
8. TRANSDUCER TYPE (ACCEL, VEL, DISP, ETC.)
9. TRANSDUCER CURRENT IN MA
10. DC Displacement Voltage (Valid only for displacement probes)
11. AXIS
12. FREQUENCY OF READING
13. AMPLITUDE (in G’s, IPS or MILS)
14. SENSITIVITY OF READING
15. PHASE (UP, DOWN, or NONE)
Example of Download Data
01/26/00, 00067, 1,A, DI-108, 1925, 40.000000, Volt., 2.0, 0.000000, NO AXIS, 50 2.501367. 10.7, UP
01/26/00, 00067, 1,B, DI-108, 1925, 40.000000, Volt., 2.0, 0.000000, NO AXIS, 516 1.586699. 10.7, NONE
01/26/00, 00067, 1,C, DI-108, 1925, 40.000000, Volt., 2.0, 0.000000, NO AXIS, 100 2.549741. 10.7, NONE
Date of
Transfer
TTS
Serial
Number
Test#
Test
Leer
Transducer
Model
Transduc-
er Seial
Number
Transduc-
er Weight
in Grams
Transducer
Type
02/22/00
02/22/00
02/22/00
00068
00068
00068
1
1
1
A
B
C
DI-108
DI-108
DI-108
1925
1925
1925
40.00000
40.00000
40.00000
VOLT
VOLT
VOLT
TABLE 3-2: EXAMPLE OF DOWNLOAD DATA
Transduc-
er Current
in mA
D.C. Displace-
ment Voltage
Test Axis#
Tri-Axial
Test Fre-
quency
Test Amplitude in
Respecve Engi-
neering Units, i.e.
IPS, MILS, G’s
Trans-
ducer
Sensivity
Transduc-
er Stack
Phase
2.0
2.0
2.0
0.000000
0.000000
0.000000
NO AXIS
NO AXIS
NO AXIS
50
516
100
2.501367
1.586699
2.549741
10.7
10.7
10.7
UP
NONE
NONE
TABLE 3-3: EXAMPLE OF DOWNLOAD DATA
Data Protocol
The host PC controls the TTS through the serial communicaons channel. Commands are sent to the
TTS at 9600 Baud, no parity and one stop bit. The TTS will execute a command or will return data to the
host.
