Metrix MX2034 - Device Communication Status; Configurable Device Settings

Doc# 100576 • REV C (Sept 2017) Page 14 of 42
 Digital Proximity Driver (MX2033) or Digital Proximity Transmier (MX2034)
 Device serial number
 Date the device was manufactured.
 Firmware model and revision number
 Hardware major.minor revision number
 Date of the last me Metrix calibrated the device
 Date the conguraon was last changed.
3.5.3 DEVICE COMMUNICATION STATUS

3.5.4 CONFIGURABLE DEVICE SETTINGS
You can congure a DPS module for:
• Probe Series
• Probe Diameter
• System Length
• Target Material
• Measurement (MX2034 only)
• Range (MX2034 only)
• 4-20mA Direcon (MX2034 only)
 
DPS is connected and communicang properly
DPS is not connected or not communicang
