Page 23 of 25
Aux Alarm Text List Messages
0 Auxiliary Alarm
1 Low Pump Room Temp
2 Reservoir Low
3 Reservoir Empty
4 Reservoir High
5 Flow Meter On
6 Relief Valve Open
7 Low Suction Pressure
8 High Pump Room Temp
9 Low Firewater Press
10 Low Purge Pressure
11 Low Gear Oil Press
12 High Gear Oil Temp
13 High Vibration
14 Gas Detection
15 Emergency Power On
16 Pump Room Door Ajar
List of possible internal variables used as inputs for aux
alarm user programs.
30 Pump Running
31 Power Available
32 Phase Reversal
33 Motor Overload
34 Remote Start
35 Local Start
36 Pump On Demand, Fire Condition
37 System Fault
38 Auto Mode
39 Manual Mode
40 Off Mode
41 Pressure Transducer Fault
42 Pump Failed to Start
43 Low Intake Shutdown Alarm
44 Supervisory Power Failure
45 Soft Start Fault
46 Low Pressure
47 Auto Weekly Test Start
48 Under Frequency
49 Over Frequency
50 Low Zone/Hi Zone Contacts
51 High Discharge Pressure
52 No Load Condition
53 Future
