3 Technical data
Range ARS 2102 SE ARS 2105 SE ARS 2108 SE
Metronix part number – with STO 9200-2102-30 9200-2105-30 9200-2108-30
Metronix part number – without STO 9200-2102-31 9200-2105-31 9200-2108-31
Auxiliary equipment Counterplug PHOENIX Mini-Combicon MC1.5/8-STF-3.81 BK
(only for devices with STO)
Power connector set 9200-0210-20 9200-0218-20
Signal connector set 9200-0200-00
Shield connector set 9200-0202-00
Ambient conditions and qualification:
Admissible temperature ranges Storage temperature: -25°C to +70°C
Operating
temperature:
0°C to +40°C
+40°C to +50°C at reduced power 2,5%/K
Admissible installation height Mounting height maximum 2000 m above msl, above 1000 m above
msl with power reduction 1% per 100 m
Humidity Relative humidity up to 90%, no bedewing
Protection degree IP20
Protection class I
Pollution degree 2
CE conformity
Low-voltage directive:
EMC directive:
2006/95/EC
verified by application of the harmonised standard EN 61800-5-1
2004/108/EC
verified by application of the harmonised standard EN 61800–3
EC product type test certificate
for the devices with STO TÜV 01/205/5245.01/14
cULus certification Listed according to UL 508C, C22.2 No. 274-13
Dimensions and weight:
Dimensions including the mounting
plate (H*W*D)
261 mm*54,6 mm*205 mm
Housing dimensions (H*W*D) 200 mm*54 mm*200 mm
Weight approx. 1,8 kg
Performance data [X9]:
Supply voltage 1 x 100 .. 230 VAC [± 10%], 50…60 Hz
Alternative DC supply 60 .. 320 VDC
24V supply
*) plus current consumption of a
possibly connected holding brake and
I/Os
24 VDC [± 20%]
(0,55 A) *)
24 VDC [± 20%]
(0,65 A) *)
Intermediate circuit voltage
for a supply voltage of 230 VAC
310 ... 320 VDC
