SECTION 4 - COUNTERSHAFT, CTRSHAFT BOX & SHEAVE ASSEMBLIES
MP SERIES CONE CRUSHER TECHNICAL REFERENCE MANUAL
4-19
Figure 4-18 Countershaft Box Seals
Callout Description Callout Description
1 O-ring 7 Countershaft box
2 Wear ring 8 No space on worn area
3 Main frame 9 Worn wear ring
4 Frame ring 10 New wear ring
5 Rectangular seal 11 Excessively worn wear ring
6 Clearance
MP1000 MP800
4
10
11 11
10
3
7
3
7
5
5
4
4
6
6 6
6
4
8 8
8 8
1
2
2
1
1
9
9
1
