SECTION 1 - GENERAL CRUSHER INFORMATION
1-4
MP SERIES CONE CRUSHER TECHNICAL REFERENCE MANUAL
Callouts
1 Feed plate 9 Bowl liner 17 Countershaft 26 Gear
33
Lower head
bushing
2 Head ball
10
Tramp release
cylinder
18
Countershaft box
guard
27 Eccentric
3 Hopper 28 Arm guard 34 Bowl
4
Adjustment
cap
11 Socket liner 19 Oil flinger
29
T- and U-seal
(lower)
35 Feed cone
12
Upper head
bushing
20 Countershaft box 36 Torch ring
5
Clamping
ring
21
Inner countershaft
bushing
30 Main frame liner 37 Locking nut
13 Socket
31
Counterweight
stationary shield
38 Main frame
6
Wedge bolt
assembly
14 Mantle 22 Pinion 39 Accumulator
15 Counterweight
23
Upper and lower
thrust bearing
32
T- and U-seal
(upper)
40 Crusher sheave
7
Adjustment
ring
16
Outer
countershaft
bushing
41 Main frame pin
24 Main shaft
8 Head 25 Eccentric bushing
1
37
36
6
5
7
8
41
12
33
15
18
16
40
19
17
20
21222425
23
26
27
28
29
30
38
31
32
10
39
38
14
9
34
13
11
2
4
35
3
Standard
Short Head
MP800 General Arrangement
