SECTION 2 - GENERAL INSTALLATION INFORMATION
MP SERIES CONE CRUSHER TECHNICAL REFERENCE MANUAL
2-15
Table 2-5 V-belt Installation And Take-up Allowances
Minimum Allowance mm (inches) Below Center Distance For Installation of Belts
Belt Length* mm (inches)
V-belt Section Minimum Allowance
Above Center Distance
For Stretch and Wear
All Sections
8V
8V
Power Band
630 (25) thru 1199 (47) — — 25 (1)
1200 (47) thru 1999 (79) — — 35 (1-3/8)
2000 (79) thru 2749 (108) 40 (1-1/2) 85 (3-3/8) 40 (1-1/2)
2750 (108) thru 3499 (138) 40 (1-1/2) 85 (3-3/8) 45 (1-3/4)
3500 (138) thru 4499 (177) 40 (1-1/2) 85 (3-3/8) 55 (2-1/8)
4500 (177) thru 5499 (216) 45 (1-3/4) 90 (3-1/2) 65 (2-1/2)
5500 (216) thru 6499 (256) 45 (1-3/4) 90 (3-1/2) 85 (3-3/8)
6500 (256) thru 7999 (315) 45 (1-3/4) 90 (3-1/2) 95 (3-1/2)
8000 (315) thru 9999 (394) 50 (2) 100 (4) 110 (4-3/8)
over 10,000 (394) 50 (2) 100 (4) 140 (5-1/2)
* In each group the range is to, but not including the second length.
