Main Frame, Adjustment Ring, Tramp Release and Clearing Jack Assemblies

Callout Description Callout Description

1 Clamping ring 5 Main frame

2 Adjustment ring 6 U-seal

3 Main shaft 7 Lower thrust bearing

4 Mainframe liner 8 Main frame pin

6 7
