Slurry Pump
WH202A1B011EN_01D.DOC JAN 04-W08
Care and maintenance
3/5
c) Carefully inspect the roller bearings, cages and races for wear, damage and
corrosion. After inspection, dip the bearings in gear oil and wrap them in a
clean cloth or paper to protect them until installation.
d) Check the condition of the shims.
e) Examine the shaft for damage and corrosion. Remove any nicks and burrs with
a carborundum stone.
f) Inspect the shaft sleeve and gaskets for deterioration, damage and wear.
Renew any gaskets which are suspect.
g) Renew any defective components.
4. Assembly
a) Slide the bearing inner races and bearing cages onto shaft (B11). Ensure that
the large outer diameter of the inner races are facing inwards on the shaft.
NOTE: ON ASSEMBLIES WITH TWO BEARINGS AT ONE END, THE ARRANGEMENT IS AS
FOLLOWS: INNER RACE, INNER SPACER, OUTER RACE, OUTER SPACER, INNER
RACE.
b) Press the bearing inner races onto the shaft so that they are tight against the
inner shoulders of the shaft.
NOTE: THE BEARINGS MAY BE HEATED IN OIL OR IN A BEARING HEATER TO A MAXIMUM
OF 121 °C FOR EASE OF ASSEMBLY.
c) Coat the shaft between the bearings with a suitable corrosion preventive
solution.
CAUTION
DO NOT GREASE THE BEARING LANDS OF THE BEARING HOUSING. THESE LANDS
SHOULD BE CLEANED WITH A PROPRIETARY DEGREASANT AND THOROUGHLY DRIED.
ENSURE THAT THE LANDS ARE FREE FROM ALL DIRT, GRIT AND CONTAMINANTS BEFORE
ASSEMBLING.
d) Push or tap a bearing outer race into the bearing cylinder housing (B14) at the
end nearest the tapped saddle screw (P20) location holes (wet-end) and
position it just below the end face of the housing. The smaller inner diameter
must be outermost. See the assembly diagram for correct orientation if in
doubt. Stand the housing on one end to assist assembly.
e) Fit grease nipples (B13) to end covers, if not already fitted. Purge greaseways
with fresh grease using a grease gun and wipe excess grease away. Ensure
that the end covers are kept clean.
f) Fit the secondary seal (B19.1) into the end-cover.
g) Place one thick end-cover shim over the spigot of end-cover (B2.1) and fit it to
bearing cylinder housing (B14) using screws (B5) so as to push the outer
bearing race into the housing. Position the end-cover so that the bearing
