Meyer Sound LD-2 - Front and Rear Panel Detail, Physical Dimensions

11
FRONT AND REAR PANEL DETAIL, PHYSICAL DIMENSIONS
3.45
19.00
16.75
The front of the LD-2, showing rack ears and corresponding space requirements
3.45
16.75
Rear
All units in inches
3.45
6.86
Side
