Page #2 background imageLoading...
Page #2 background image
Protective earth ground
Terre de protection
Die schutzerde
Tierra proteccionista
Frame or chassis
Masse, châssis
Rahmen oder chassis
Armadura o chassis
Important operating
instructions
Pour indequer important
instructions
Zu wichtige betriebs-
anweisung und unter-
haltsanweisung zeigen
Para indicar importante
funcionar y mantenimiento
instrucciones
Dangerous voltages:
risk of electric shock
Pour indiquer les risques résultant
de tensions dangereuses
Zu die gefahren von
gefährliche spanning zeigen
Para indicar azares provengo
de peligroso voltajes
2
CONTENTS
DECLARATION OF CONFORMITY ACCORDING TO ISO/IEC GUIDE AND EN 45014
The Manufacturer:
MEYER SOUND LABORATORIES, INC.
2832 San Pablo Avenue
Berkeley, California 94702-2204, USA
Declares that the product:
LD-2
Conforms to the following Product Specifications
Safety: EN60065: 1994
EMC: EN55103-1 emmission
1
EN55103-2 immunity
2
0° to + 45°
<-40°C or > +75°C
to 95% at 35°C
to 4600 m (15,000 ft)
to 6300 m (25,000 ft)
30g 11 msec half-sine on each
of 6 sides
10Hz to 55Hz (0.010m
peak-to-peak excursion)
Operating Temperature
Nonoperating Temperature
Humidity
Operating Altitude
Nonoperating Altitude
Shock
Vibration
E
NVIRONMENTAL SPECIFICATIONS FOR MEYER SOUND ELECTRONICS PRODUCTS:
Safety Summary 3
The LD-2 Line Driver: Introduction 4
Audio Input 4
AC Power 5
Left And Right Channel Funtions 5
Example Configurations 6
Specifications 8
LD-2 Signal Flow Diagram 9
Front and Rear Panel Detail, Physical Dimensions 10
Notes 11
Contact Information 12
This device complies with the requirements of the Low Voltage
Directive 73 / 23 / EEC and the EMC Directive 89 / 336 / EEC.
This device also complies with EN 55103-1 & -2. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
T
HESE SYMBOLS INDICATE IMPORTANT SAFETY OR OPERATING FEATURES IN THIS BOOKLET AND ON THE CHASSIS.
!
SYMBOLS USED
Office of Quality Manager
Berkeley, California USA August 31, 2000
European Office:
Meyer Sound Lab. GmbH
Carl Zeiss Strasse 13
56751 Polch, Germany
Made by Meyer Sound Laboratories
Berkeley, California USA
N757 LD-2
3K59 COMMERCIAL
AUDIO SYSTEM
